Description

geo-FENNEL FKL 55 (LC 2) RED Beam Pipe Laser Level

Product Overview

Our newest generation of pipe lasers with advanced technologies and improvements.

• Advanced technology of mechanical parts, temperature stability and grade technology
• Extremely good visibility of OLED-Display with large figures
• Long-range IR remote control with 100 m working range
• Laser spot direction setting: Quick shifting by continued pressing respective button at both laser or remote control

Rugged, waterproof, powerful, easy operation and comprehensive range of standard accessories.

Features

• Robust aluminium housing
• Easy intuitive operation
• Fully automatic self-levelling
• Automatic beam centering
• Laser start point indication
• Clear easy-to-read OLED-Display
• IR remote control with long working range
• Integrated rechargeable batteries

Includes

• Target frame with target DN 150–300
• Container
• Pipe Laser
• IR remote control
• Leg set DN 500
• Leg set DN 400
• Leg set DN 300
• Leg set DN 250
• Leg set DN 200
• Adapter for 3-leg set up
• Charger
• Battery case for alkaline batteries
• Target DN 400–500

Specifications

• Laser class : 2
• Laser diode : red
• Beam diameter : 10 mm
• Working range : up to 120 m
• Grade range : -20 % – +30 %
• Self-levelling range : ± 5°
• Minimum display reading : 0,000 %
• Horizontal accuracy : ± 5 mm / 100 m
• Left / right scanning : ± 4°
• Operating time : 24 h (NiMH)
• Power supply :
  – 4 x D 8000 mAh NiMH
  – (optional 4 x D Alkaline)
• IR remote control range
  – front / back : 100 m / 50 m
• Temperature range : -20 °C – +50 °C
• Dust / water protection : IP 68
• Dimensions : Ø 132 mm, length 380 mm
• Weight (laser only) : 6 kg
