geo-FENNEL FL 265HV (LC 2 & LC 3R) Red Beam Rotating Laser Level

Model obsolete, contact us for other alternatives.

Receiver Option

• FR 77-MM Laser Detector
• FR 45 Laser Detector

Product Overview

The latest generation of the “Best in class”

• New innovative low friction drive mechanism and self-levelling module
• Accurate, robust and temperature stable
• Low friction drive for reduced noise generation

User-friendly operating concept

• For the ultimate in ease-of-use the only control functions on the instrument power on/off the laser beam and the remote control
• All additional functions including scanning and slope setting are accessed from the remote control

Improved performance

• Robust remote control with 100 m range

Features

• The Premium horizontal and vertical laser for all interior and outdoor applications
• Dust / water protection IP 66
• High accuracy of ± 0,5 mm / 10 m
• Working range 800-1000 m diameter (depending on model)
• Enhanced scanning functions with small increments and a range up to 180°
• Permanent 90° beam for right angles
• Automatic TILT alarm function
• VWS function (Vibration-Wind-Security)
• Auto-shut-off when out of level
• Remote control function on/off: to avoid   interference with other remote controls   or mobile devices
• Manual slope setting of X and Y axis or  auto self-level of opposite axis
• Floor mount with centring mark for accurate   set up above a ground point
• Li-Ion battery technology

Includes

• Receiver FR 77-MM with clamp
• Remote control
• Rechargeable batteries
• Charger
• Battery case for alkaline batteries
• Floor mount
• Magnetic target
• Laser glasses
• Carrying case

Specifications

• Self-levelling range : ±5°
• Laser class : 2
• Accuracy horizontal : ± 0,5 mm / 10 m
• Accuracy vertical : ± 1,0 mm / 10 m
• Working range with receiver FR 77 Ø : 800 m
• Manual slope setting X axis : ± 5° (±9%)
• Manual slope setting Y axis : ± 5° (±9%)
• Remote control range : IR 100 m
• Rotating speed : 300, 800
• Operating time : 50 h / Li-Ion
• Temperature range : -20° – +50°C
• Dust / water protection : IP 66
