Description
geo-FENNEL FL 505HV-G (LC 2) Dual Grade Rotating Laser Level
The versatile dual grade laser
- Improved performance ulilising PowerSwitch-Technology:
- The power of a class 3R in a class 2 laser.
- 4 mm laser beam diameter for optimised compatibility with our FMR 700/800 over long distances
- Now with receiver FR 80-MM with mm-Indication as standard
- Fully automatic self-levelling in horizontal, vertical and grade
- Slope functions horizontal:
Digital grade setting of X and Y axis up to ±10 %
Manual slope setting of X and Y axis - Slope functions vertical:
Direction of X axis can be set up to ±10 % with Y axis self-levelled
Direction of X and Z axis can be set manually
Features
-
Dual Axis Laser
-
Horizontal and vertical
-
Digital grade adjustment
-
Monitored grade
-
TILT function
-
VWS function
-
90° beam to zenith
-
Illuminated display
-
2 way RF remote control
-
Manual function
-
4-step scanning function
-
Operation with rechargeable Li
-
Ion or alkaline batteries
-
Dust / water protection IP 66
Includes
-
Receiver with clamp
-
2-Way RF Remote ctrl
-
Li-Ion battery & charger
-
Vertical mount
-
Telescope
-
360° horizontal fine adjustment bracket
-
Container
Specifications
- Self-levelling range ± 8°
- Accuracy horizontal ± 0.5 mm / 10m
- Accuracy vertical ± 1 mm / 10 m
- Scanning w/o receiver 60 m*
- Rotating w/o receiver Ø 60 m*
- Laser diode / Laser class 2
- Scanning ranges 0°, 10°, 45°, 90°, 180°
- Horizontal slope setting
– X axis ± 10.000 %
– Y axis ± 10.000 %
-X and Y axis ∑ ± 14 % - Vertical slope setting
– X axis ± 10.000 %
– Y(Z) axis horizontal self-levelled - Rotating speed 300 / 600 / 1100 rpm
- Operating time 40 h
- Power supply intelligent / Li-Ion
- Alkaline batteries (optional)
- Remote control range 150 m
- Remote control channels 9
- Temperature range -10 °C – +50 °C
- Dust / water protection IP 66
- Weight (instrument only) 3.85 kg
