Description
geo-FENNEL S-Digit 60 Plus + Digital Level Angle Measurer
Our latest generation of inclinometers with a new enhanced tilt sensor, that offers the following:
- Fast reaction time
- A stable display for improved accuracy
- Improved thermal stability
- Zero position re-set at any position
- Illuminated display
Robust slope measurer. Length 60 cm. Incorporated laser beam.
Features
- Different signal tones when approaching 0° / 90° and continuous tone at 0° / 90°
- Inclination direction indication
- Zero position re-set at any position
- Automatic digit inversion for overhead measurements
- Visible laser beam to extend working range
- HOLD function to freeze measurement
- Illuminated display
- 1/4” thread for camera tripod
Includes
- Padded bag
- Batteries
Specifications
| Working range | 4 x 90° |
| Resolution | 0.1° / 0.1% |
| Accuracy | 0° and 90° = ± 0.1° |
| Accuracy | 1° – 89° = ± 0.2° |
| Measuring units | °, %, mm/m, in/ft |
| Working range laser | 20 m |
| Accuracy laser | ± 0.5 mm / 1 m |
| Wave length / laser class | 650 nm / 2 |
| Power supply | 3 x AA Alkaline |
| Operating time | w/o laser 50 h |
| with laser 20 h | |
| Temperature range | -10 °C – +45 °C |
| Weight (incl. Batteries) | 0.86 kg |
| Size | 600 x 60 x 32 mm |
