Description
Leica DA175 1 Watt Signal Transmitter
- 1 Watt option.
- Compatible with DD120, DD130 and DD175 locators
- Trace frequencies: 512Hz, 640Hz, 8kHz, 33kHz and combined (8kHz + 33kHz)
- 4x LR20 Alkaline Battery
- IP67 rating
- Includes: Earth Spike, Crocodile clip connector & cables
The Leica DA175 transmitter is a 1-watt signal transmitter which is designed to work with the Leica DD series of utility locators, including DD120, DD130, and DD175.
This device send a traceable signal onto underground utilities, enhancing the capabilities of your existing Leica DD locators.
The Leica DD Series is designed for
- Civil Companies
- Engineering companies
- Plumbing companies
- Utility installers
- Excavation professionals
DA175 1 Watt Transmitter
|
Induction |
Up to 1 Watt max. |
|
Connection mode |
Model dependent, up to 1 Watt or 3 Watt, when connected to a buried utility with an impedance of 300 Ohms |
|
Operating transmission frequencies |
131.072 (131) kHz |
|
Display panel |
LED Indicators: |
|
Keypad |
4 membrane push buttons |
|
Audio |
85 dBA @ 30 cm |
|
Battery type |
7.4 V Li-Ion pack |
|
Typical operating time 3 Watt, 1 Watt |
15 hours at power level 2 connection mode |
|
Dimensions |
250 x 206 x 113 mm/9.84 x 8.11 x 4.45 inches |
|
Weight (incl. standard accessories and batteries) |
2.38 kg with Li-Ion |
|
Temperature |
Operating -20°C to +50°C, -4°F to +122°F |
|
Protection against water, dust and sand |
Conforms to IP67 lid open or closed |
|
Humidity |
95% RH non condensing |
|
Approvals |
CE, FCC |
| Datasheets | |
|---|---|
| Leica DA175 1 Watt Signal Transmitter – Datasheet | |
| Specifications | |
| Leica DA175 1 Watt Signal Transmitter – Specifications | |
