Description

Leica Disto D810 Touch PACKAGE Laser Measurer

Product Overview

Leica Disto D810 Video

Large touchscreen for intuitive use, camera function, measurements inside a picture, Bluetooth(R) smart

The professional package for convenient aiming and precise measurement Precise measuring over long distances requires a stable set-up of the laser distance meter. It is often difficult to make fine adjustments to precisely aim at the targeted area, even when the tool is directly mounted on a tripod. We have addressed this challenge with this new professional solution.

The new Leica FTA360 adapter has a fine adjustment system for convenient and accurate targeting, which fits perfectly with our Leica tripod TRI 70. Together with the FTA360 adapter the Leica DISTO™D810 touch becomes a highly precise measuring solution.

• Fine adjustment of the laser dot at the target point by holding the device to a stable reference
• Precise aiming and measuring on small objects and large distances
• Package specifically designed for exterior applications
• Complete package in a robust, attractive, and functional carrying case
• Each product and accessory is visible in the case, so nothing will be lost or forgotten
• Cases are designed to be stacked on top of each other

Leica DISTO™ D810 touch – the smartest solution for measuring and documenting
The Leica DISTO™ D810 touch is the world’s first laser distance meter with a touch screen and revolutionary “measure with a picture” feature. You can take pictures with the integrated camera and easily transfer them to a computer. The high level of functionality is perfectly completed by the smart free app Leica DISTO™ sketch, which is available for Android and iOS devices.     Leica tripod adapter FTA360 – Smart accessory enables extreme precision
The robust tripod adapter FTA360 with fine drive guarantees a convenient and precise targeting with the Leica DISTO™ D810 touch. The adapter makes it easier to aim over long distances and increases the accuracy when taking indirect measurements.     Leica TRI 70 – The small and compact tripod for everyday use
The small, portable crank tripod Leica TRI 70 is intended for everyday use. It provides a working height of up to 120 cm. The integrated bubble level allows for simple, straight forward set-up.     Leica carrying case – Robust, attractive and functional
The Leica carrying case provides convenient and safe transportation of your measuring and alignment equipment. It is made of high quality plastic, which makes it very durable. Tools and accessories are easily accessible in the case and you will have everything you need to get the job done right.

Features

• Minimum / Maximum
• Permanent measurement
• Plus / minus
• Area / volume
• Room function summary
• Indirect height measurement (Pythagoras)
• Measurements despite obstructions
• Measurement of facade areas
• Bluetooth (R)
• 360° tilt sensor for measurement of any slope (even overhead)

Includes

• Leica DISTO™ D810 touch laser distance meter
• Holster
• Hand loop
• USB charger incl. 4 plugs
• Leica FTA360 tripod adapter
• Leica TRI 70 tripod
• Carrying case

Specifications

Distance	0.05 – 200 m
Accuracy	± 1,0 mm
Dust / water protection	IP 54
Weight	238 g
Laser class	2

ISO 16331-1 certified typical measuring accuracy	±  1.0mm
ISO 16331-1 certified typical measuring range	up to 100 m*
Measuring units	0.000 m, 0.0000 m, 0.00 m, 0.00 ft, 0’00” 1/32, 0.00 in, 0 in 1/32
Power Range Technology	Yes
Pointfinder with 4x zoom	Yes
Overview camera	Yes
Photograph file format	.jpg
Memory	Last 30 displays
Windows Software	DISTO Transfer with AutoCAD® plugin
Free App	iOS / Android
Data interface*	Bluetooth® V4.0 Smart
Measurements per set of batteries	up to 4000**
Multifunctional end-piece	Automatic recognition of measurement position
Batteries	Li-ion rechargeable
Tripod thread	¼”- 20
Protection class	IP 54 – splash water/ dust proof
Dimensions	164x61x31 mm
Weight with batteries	238 g
EAN/UPC	7640110694640

Download Brochure
