Description
- Measuring acceleration and velocity
- Velocity Range 200mm/s²
- Min / Max
- Frequency 10Hz – 1KHz
- Separate vibration probe with magnetic base
- RMS and peak measurement
- Microprocessor based
The MT965 is a portable vibration meter used for measuring acceleration and velocity. All industrial machinery vibrates therefore knowing the level of vibration is a useful guide for determining the machine condition. Poor balance, misalignment and looseness of the structure will cause the vibration level to increase. This is a sure sign that maintenance is needed. The MT965 has a microprocessor and is the ideal instrument for industrial vibration monitoring.
Specifications
| Function | Range | Accuracy |
| Velocity Range | 0.5 – 199.9mm/s² | |
| Acceleration Range | 0.5 – 199.9m/s² | |
| Frequency Range | 10Hz – 1KHz | ±(5% +2) 160 Hz, 80Hz |
| Calibration Point Velocity | 50mm/s (160Hz) | |
| Calibration Point Acceleration | 50m/s² (160Hz) | |
| Display | LCD Screen | |
| Sample Rate | 1 second | |
| Min Max Ave | Yes | |
| Overrange Indication | Yes | |
| Peak Measurement | Yes | |
| Data Hold | Yes | |
| Back Light | Yes | |
| Enclosure | Over moulded casing | |
| Low Battery Indication | Yes | |
| Battery | 9V | |
| Weight Meter | 274g | |
| Weight Probe | 38g | |
| Dimensions Meter | 185 x 78 x 38mm | |
| Dimensions Probe | 16mm dia x 29mm | |
Includes:
- Carrying Case
- 9V Battery
- Vibration sensor
- Instruction manual
- Magnetic base
Downloads
MT965 Instruction Manual
