Radiodetection SmartChariot Ground Penetrating Radar Systems

Description

SmartChariot™

Systems include DVL-500, GPR sensor, configuration, cable, battery and charger

Mode of Operation:

The SmartChariot™ provides vehicle-towed deployment of NOGGIN® 250, 500 or 1000 systems. It is ideal for surveys covering large, smooth, open areas that can be performed using a vehicle: roads, highway sections and bridges needing quick assessment, large parking lots, parking garages, and open fields such as golf courses and parks.
The SmartChariot™ attaches to a common trailer hitch on any vehicle: cars, trucks and vans, but also ATV’s (all-terrain vehicles), tractors and even bicycles and motorcycles can be used.

SmartChariot™ features:

• A wheel odometer to trigger data acquisition at default or user-defined intervals (step size) to provide uniform data coverage.
• Sensors & Software’s unique DynaQ® feature automatically adjusts data acquisition rates to the survey speed; providing dynamic stacking to maximize data quality.
• A mount for a GPS receiver (GPS optional).
• Brackets to quickly swap between the NOGGIN® 250, 500 and 1000 systems.
• The ability to deploy two Noggins simultaneously: a NOGGIN® 500 and a NOGGIN® 1000.

Options:

The following optional items are available to customize the system for your needs.

• GPS to provide geo-referenced coordinates linked to the data
• Smaller or longer-life batteries depending on the time duration of measurements or portability requirements

Supported Sensors:

The SmartChariot™ supports the NOGGIN® 250, 500 or 1000 sensors.

Downloads

• NOGGIN® brochure – English
• NOGGIN® CATALOG
• NOGGIN® Ultra 100
• NOGGIN® brochure – Chinese

.
