Description
DISCONTINUED
Contact us for options!
ZM12 laser modules are equipped with a Ø 15mm laser head and an M12 thread, suitable for applications with limited installation volume, such as small sensors and measuring heads. The ZM12B offers a simple focusing mechanism and powers up to 40mW with complete water and dust protection.
Models
- 5mW (2-3m line), fixed focus and focusable
- 10mW (3-5m line), fixed focus and focusable
- 15mW (4-6m line), fixed focus and focusable
- <1mW (Dot, elliptical), focusable
Additional Information
| Weight | 67 g |
|---|---|
| Dimensions | 85 × 15 mm |
| Wavelength |
635 nm, 640 nm |
| Output power |
10 mW, 15 mW, 20 mW, 30 mW, 5 mW |
| Beam angle |
10°, 20°, 30°, 45°, 60°, 75°, 90° |
| Projection |
Cross, DOE, dot, line |
| Focus |
fixed focus, manual focus |
| Diameter |
15 mm |
| Supply voltage |
5 VDC – 30 VDC |
| IP protection class |
IP 67 |
| Application |
Machine Vision, OEM, Positioning |
