Description
(item no. 3474946)
Amprobe BAT-500 Battery Tester quickly and accurately tests batteries without taking the batteries off-line. This Battery Tester features a comparator function with pass/fail indication, and speed testing of batteries up to 500Ah. Amprobe BAT-500 Battery Tester, compact and light weight, simultaneously measures battery resistance and voltage up to 40V.
Features
- Tests battery Impedance to calculate its true life
- Works with most batteries, compact storage batteries, alkaline and lead-acid up to 500Ah
- Resistance measurement up to 40 ohms, and voltage up to 40V
- Tests are performed without shutting down a battery
- Simultaneously measure battery resistance and voltage
- Comparator function to quickly access conditions as pass, warning, or fail
- 99 memory locations to store results with read function
- Compact and lightweight
- RS232 PC interface to download testing results to a PC for trending/life cycle analysis
- Instruction manual, batteries, test probe, software, RS232 cable
Specifications
| Features | BAT-500 |
| Maximum battery capacity | Up to 500 amp hours |
| Battery type | Alkaline, nickel-metal hydride (NiMH), nickel-cadmium (NiCd), lithium-ion (Li-ion) and lead-acid batteries |
| DC Voltage | 4.000 V, 40.00 V |
| Impedance | 40 mO, 400 mO, 4 O, 40 O |
| Data capture memory | 500 data sets |
| Data logging memory | 9600 data sets |
| PC Download | • |
| Specifications | |
| Battery capacity: | 0 to 500AH |
| Resolution: | 10µO, 100µO, 1mO, 10mO |
| Accuracy: | ±(1%reading ±10digits) |
| Open circuit voltage: | 3.5Vpp max |
| Measurement current: | 25mA approx., 2.5mA approx., 250µA approx., 25µA approx |
| Measuring current frequency: | 1KHz ±10% |
| Voltage measurement range: | 4V, 40V |
| Resolution: | 1mV, 10mV |
| Accuracy: | ±(0.1% rdg ±6 digits) |
| Model Name | Description |
| BAT-500 |
Included Accessories: Users manual, software manual, batteries, RS232C9 to USB Bridge), cable, software CD, kelvin clips |
