Description

CHCNAV HCE600

Rugged Field Controller for Surveying and Mapping

Highlights
The HCE600 is a lightweight, professional Android data collector designed for field surveying and mapping. With a 5.5-inch DragonTrail™ display, it offers exceptional durability and clear visibility in sunlight. Packed with Bluetooth 5.0, dual-band Wi-Fi, and a 4G modem, it ensures seamless connectivity with GNSS receivers and RTK networks. Certified to IP68 and MIL-STD-810H standards, the HCE600 is built to withstand harsh environments, making it the ideal handheld controller for reliable data collection in any conditions.

Main Features

DragonTrail™ Glass
5.5-inch HD+ screen with 500 nits brightness.

Rugged
IP68 and MIL-STD-810H for dust, water and shock resistance.

Long Battery Life
6240 mAh battery for up to 14 hours of continuous operation.

High Connectivity
Bluetooth 5.0, dual-band Wi-Fi, 4G modem.

Benefits and Performances

Powerful Performance
Achieve high performance with the Helio MTK 6762 octa-core processor running at up to 2 GHz. Android OS coupled with 3GB of SDRAM and 32GB of flash memory ensure smooth operation and efficient data processing.

High-Visibility Display
Work efficiently in any lighting condition with the 5.5-inch, 500 nits HD+ display. The screen provides clear, legible data even in direct sunlight, enabling uninterrupted fieldwork.

Comprehensive Connectivity
Enjoy seamless connectivity to GNSS receivers and RTK networks with Bluetooth 5.0, dual-band Wi-Fi (2.4G/5G) and a built-in 4G modem. The HCE600 ensures reliable communication and data transfer in the field.

Rugged and Durable Design
The HCE600’s IP68 and MIL-STD-810H-rated housing can withstand harsh field conditions. The DragonTrail™ glass display offers scratch resistance and durability for long-term performance.

Lightweight and Ergonomic
Work in comfort with the HCE600’s lightweight (345g) and ergonomic form factor. The one-handed grip and customizable shortcut keys enhance the user experience and make it easier to collect data.

Extended Battery Life
The HCE600 lithium-ion battery provides up to 14 hours of continuous use without frequent recharging, allowing you to work all day in the field.

Specification

Display
Screen size : 5.5″ touchscreen
Screen resolution : 1440 x 720
Positioning
GNSS : GPS, GLONASS, Galileo, BeiDou
System
Operating System : Android
Processor : Octa-core 2.0 GHz
Memory : 3 GB SDRAM – 32 GB ROM
Connectivity
Wireless : Bluetooth, Wi-Fi, NFC
Cellular : 4G LTE, GSM, WCDMA

CHCNAV i83 Rover Kit

Name: CHCNAV i76 GNSS Receiver with HCE600 Rover Kit and SMA Whip Antenna
Brand: CHCNAV
SKU: 8001010410
Availability: InStock

Smart IMU-RTK GNSS with Robust Connectivity

Highlights
The i83 GNSS receiver is a powerful IMU-RTK GNSS solution built for surveying, construction, and mapping professionals. Equipped with Wi-Fi, Bluetooth, NFC, UHF, and a 4G modem, it delivers versatile connectivity across multiple applications. Its power management allows 34 hours of continuous RTK rover operation, ensuring reliable performance for extended fieldwork.

Main Features

Comprehensive Connectivity
Wi-Fi, Bluetooth, NFC, UHF, and 4G for seamless data transfer.

1408 GNSS Channels
Support GPS, GLONASS, Galileo, BeiDou, QZSS and SBAS constellations.

Tilt Compensation
+30% surveying efficiency with calibration-free IMU sensor.

Rugged Design
IP67 and MIL-STD-810H for dust, water, shock, and vibration resistance.

Benefits and Performances

High-Performance GNSS
The i83’s 1408 channel supports GPS, GLONASS, Galileo, BeiDou, QZSS and SBAS constellations to achieve reliable centimeter-level positioning accuracy in challenging environments, improving surveying quality and efficiency.

Comprehensive Connectivity
The i83’s built-in connectivity includes Wi-Fi, Bluetooth, NFC, UHF and a 4G modem. It provides easy integration with field controllers and tablets, support for multiple GNSS surveying modes, and efficient data transfer and communication.

Pole Tilt Compensation
Increase surveying efficiency by up to 30% with the i83’s calibration-free IMU sensor, which can measure at up to a 60 degree tilt, providing accurate data without the need for perfect pole leveling.

High-Resolution Display
Monitor receiver status with ease on the 1.1″ color OLED display. The display provides clear, real-time information on the i83’s operating status, enhancing user control and survey accuracy.

Rugged and Durable Design
Survey in harsh environments with confidence. The i83’s rugged magnesium alloy body ensures durability and reliable performance in tough field conditions.

Extended Battery Life
Work without interruption with the i83’s 9600 mAh battery, which provides up to 34 hours of continuous RTK rover operation and up to 16 hours of RTK base operation.

Positioning
GNSS : Full GNSS
IMU : 200 Hz
Precision max. : 0.8 cm H / 1.5 cm V
Connectivity
Wireless : Bluetooth, Wi-Fi, NFC
Cellular : 4G LTE
Modem : 410-470 MHz, Rx/Tx
Physical
Weight : 1.15 kg
Dimensions : 152 x 78 mm
Battery life : Up to 34 hours RTK rover

Includes – i83 W/ HCE600 Rover Kit	1
i83 GNSS Receiver	1
UHF Whip Antenna(450-470MHz KQT450GT）	1
Type-C USB Cable	2
Transport Hard Case/ Rover	1
Transport Hard Case/ rover inner carton box	1
Transport Hard Case/ rover outer carton box	1
GNSS Receiver Case Label (CHCNAV)	1
Range Pole (AR)	1
Auxiliary H.I. Tool (Silver)	1
Power Adapter (5V2.4A)	2
HCE600 Handheld GNSS Data Collector W/Hand Strap	1
Android Stylus	1
Controller Bracket（Cramp）	1
Landstar 8 Data Collection Software (Android)	1
