Spectra Precision HV1305C Complete Setup: HL760 Receiver, C70 Detector, RC1402 Remote, Vertical Adapter & NiMH Batteries

Description

A new generation in visibility and versatility is here!

The automatic self-leveling Spectra Precision® HV1305C red beam laser is the most rugged, cost-effective lasers that provide both horizontal and vertical alignment. Even in harsh job site conditions, the lasers deliver consistently reliable and accurate performance, enabling you to work faster and smarter.

Key features & benefits:

Complete leveling crew in a case – carrying case securely holds all components, tripod and grade rod (valid for the complete system kit)

• Automatic horizontal and vertical self-leveling

• Accuracy 1.5mm @ 30 m (1/16 inch @ 100 ft)

• Working range of up to 1200m (4,000 ft) diameter with HL760

• High-visibility beam – easily visible even in brightly lit conditions

• Height of Instrument Alert – unit stops rotating when jarred to avoid erroneous readings

• Rotation selection of 0,10,100, 200,300 or 600 RPM

• Remote control or remote control app allows operation of all laser functions from anywhere on the job site

• Bluetooth connection allows laser control with a smartphone

• Extremely durable and portable with a 5 Year warranty

Specifications

Leveling Accuracy

 ± 1.5 mm/30 m, 1/16“ @ 100 ft.

10 arc seconds

Operating Diameter w/HL760

 Typ.1200 m (4000 feet)

Rotation

Preset 0, 10, 100, 200, 300 and 600 rpm Adjustable in 10 rpm increments >100rpm

Scan Angles

Preset 5°, 15°, 45° and 90°

Adjustable in 5° increments

Laser Type

630 – 643 nm

Laser Class

HV1305C Class 2

HV1305C Class 3

(Class 2 available in Europe)

Self-leveling Range

Typ. ± 5° (± 8.7%)

Leveling Indicators

LED flashes

Radio Range (HL760)

up to 100 m (330 ft)

Power Source

10,000 mAh NiMH battery back

or 4 x 1.5V D alkaline batteries

Battery Life

HV1305C up to 45 hours

HV1305GC up to 30 hours

Battery Charging Time

< 10 hours

Operating Temperature

-20°C to +50°C (-4°F to +122°F)

Storage Temperature

 -25°C to +70°C (-13°F to +158°F)

Tripod Attachments

5/8 x 11 horizontally and vertically

Dust and Waterproof

Yes – IP66

Weight

3.49 kg (7.7 lbs)

(incl. Battery pack)

Low Voltage Indication

LED battery indicator

Product Dimensions

240mm x 280mm x 180mm

(9.45 in x 11.02 in x 7.09 in)

Warranty

5 Years

What’s Includes

• HV1305C
• Hl760
• C70
• RC1402
• Veritcal Adaptor
• Nimh Rechargeable Batteries
• Charger
• Ceiling Target
• Glasses
• Small Case
