Description
HIKMICRO M20 handheld thermography camera is specially designed for professional inspections. It’s equipped with a 256 × 192 resolution thermal detector and an 8MP resolution visual camera. The high resolution 3.5-inch touch screen displays crisp, clear images and streamlines camera operations. Imaging modes include thermal, visual, picture in a picture of the optical and thermal view, and fusion of both channels. The M20 quickly identifies potential faults, quantifies the impact with accurate temperature measurement, provides detailed documentation to complete your inspections efficiently.
Features
- High sensitivity thermal module with 256 × 192resolution
- Supports multiple palettes
- High quality optical module with 8 MP resolution
- Bi-spectrum image fusion, picture-in-picture preview
- Wide temperature measurement range: -20 – 650° C
- High temperature measurement accuracy: Max ±2°C for 0 to 100°C, ±2% for 100 to
- 600°C, ±4% for 600 to 650°C at the ambient temp. 15 to 35°C
- 640 x 480 resolution 3.5” LCD touch display
- Long-distance laser light supplement for thermography targets
- LED light supplement makes the device a torch in required scenarios
- 1.0x to 8.0x continuous digital zoom
- Supports remote album access, download and quick report with APP
| Infrared Image | ||||||||||||||||
| IR Resolution | 256 × 192 (49,152 pixels) | |||||||||||||||
| SuperIR | 512 × 384（196,608 pixels） | |||||||||||||||
| NETD | <40 mK (@ 25 °C, F#=1.0) | |||||||||||||||
| Image Frequency | 25 Hz | |||||||||||||||
| Detector Pitch | 12 μm | |||||||||||||||
| Spectral Range | 7.5 to 14 μm | |||||||||||||||
| Focal Length | 6.9 mm | |||||||||||||||
| F-number | F1.0 | |||||||||||||||
| Field of View (FOV) | 25° × 18.8° | |||||||||||||||
| Spatial Resolution (IFOV) | 1.74 mrad | |||||||||||||||
| Min. Focus Distance | 0.1 m (0.33 ft) | |||||||||||||||
| Focus Mode | Manual Focus | |||||||||||||||
| Image Display | ||||||||||||||||
| Visual Camera | 3264 × 2448 (8 MP) | |||||||||||||||
| Display | 640 × 480 Resolution, 3.5″ LCD Touch Screen | |||||||||||||||
| Screen Brightness | Manual | |||||||||||||||
| Digital Zoom | 1.0x to 8.0x continuous | |||||||||||||||
| Color Palettes | White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red, Condensation Alarm |
|||||||||||||||
| Focus Mode Palette | Above/Below/Interval | |||||||||||||||
| Color Alarm | Above/Below/Interval/Insulation | |||||||||||||||
| Image Modes | Thermal/Visual/Fusion/PIP/Blending | |||||||||||||||
| Measurement and Analysis | ||||||||||||||||
| Object Temperature Range | Range -20℃ to 150℃（-4°F to 302°F) Range 100℃ to 650℃（212°F to 1202°F） |
|||||||||||||||
| Accuracy | Max ±2°C for 0 to 100°C, ±2% for 100 to 600°C, ±4% for 600 to 650°C at the ambient temp. 15 to 35°C |
|||||||||||||||
| Measurement Tools | Center Spot, Hot Spot, Cold Spot User-definable: 10 spots, 1 line, 5 rectangles, and 5 circles |
|||||||||||||||
| Level and Span Mode | Auto/Manual/1-Tap Touch-screen | |||||||||||||||
| Data Storage and Communication | ||||||||||||||||
| Image Storage Capacity | Approx. 60,000 Images (8MP) | |||||||||||||||
| Annotations | Voice note: max. 60 seconds; Text note: max. 200 characters; QR Code note; Picture note；Tag note; Sketch; |
|||||||||||||||
| Video Storage Capacity | MP4 video max. 160h; Radiometric video max. 50h |
|||||||||||||||
| Video File Format | MP4 video and radiometric video | |||||||||||||||
| Radiometric Infrared-Video Streaming (Compressed) |
Over UVC, Wi-Fi | |||||||||||||||
| Extendable Memory Card | Extendable 32 GB Micro SD Card | |||||||||||||||
| General | ||||||||||||||||
| Wi-Fi | 802.11 b/g/n (2.4 GHz and 5 GHz) | |||||||||||||||
| Bluetooth | Bluetooth 4.2 | |||||||||||||||
| USB Interface | USB Type-C | |||||||||||||||
| Battery Type | Interchangeable and rechargeable Li-ion battery | |||||||||||||||
| Laser | Yes, Class II, Wavelength: 635 nm; Power: <1 mW | |||||||||||||||
| Battery Operating Time | Approx. 6 hours | |||||||||||||||
| Battery Charging Time | Approx. 4 hours fully charged | |||||||||||||||
| LED Light | Yes | |||||||||||||||
| Protection Level | IP54 | |||||||||||||||
| Drop Test Height | 2 m (6.56 ft) | |||||||||||||||
| Safety | IEC 61010-1 | |||||||||||||||
| EMC | EN 50130-4, EN 55032, EN IEC 61000-3-2, EN 61000-3-3 | |||||||||||||||
| Vibration | 1 g, IEC 60068-2-6 | |||||||||||||||
| Shock | 15 g, IEC 60068-2-27 | |||||||||||||||
| Working Temperature Range | -10°C to 50°C (-4°F to 122°F) | |||||||||||||||
| Storage Temperature Range | -20°C to 70°C (-4°F to 158°F) | |||||||||||||||
| Relative Humidity | <95% non-condensing | |||||||||||||||
| Weight | Approx. 660g (1.46 lb) | |||||||||||||||
| Dimension | 244 × 100 × 104 mm (9.6 × 3.9 × 4.1 in) | |||||||||||||||
| Tripod Mounting | UNC ¼”-20 | |||||||||||||||
| Warranty | 3 years for the full product, 10 years for the detector, and 2 years for the battery. | |||||||||||||||
| Power Saving Mode | Yes | |||||||||||||||
