Leica Digitex 100t Transmitter
Product Overview
Leica Digitex signal transmitters deliver significantly higher power than previous models. This improved performance will allow users to:
- Trace utilities over a greater distance
- Improve utility detection in areas of high signal interference
- Improve depth estimation when using a depth locator
Direct Connection
Connect the Digitex to a conductive utility such as a valve, stop tap or another access point.
Signal Clamp Connection
A signal clamp is used to apply the Digitex signal to a pipe or live electricity cable. Supply is not interrupted by the signal and the operator is not exposed to any live utility.
Induction
The Digitex induces a tracing signal into the buried pipe or cable. This is a quick and convenient method when direct connection or signal clamping is not possible.
Features
- To improve utility detection in areas of high signal interference
- Enables depth estimation, when using a depth enabled cable locator
- Enables to locating of non-conductive utilities by applying a detectable signal to underground utilities. The signal can then be traced using a Leica DIGICAT cable locator. Using the Leica DIGITEX signal transmitters this way will help you locate around 50% more buried cables or pipes than using a DIGICAT cable locator alone.
- Use a range of accessories to locate a range of utilities
Specifications
| 8 kHz Mode | 8.192 kHz |
| 33 kHz Mode | 32.768 kHz |
| Mixed 8/33 | 8.192 kHz/32.768 kHz |
| Induction (Max) | >Up to 1W max |
| Direct connection (300 Ohms) | Up to 1W max when connected to a buried utility with an impedance of 300 Ohms |
| Protection (case lid closed) | IP67 |
| Working temperature | –20°C to +50°C |
| Battery type | 4 x D alkaline (IEC LR20), supplied |
| Battery life (typical use at 20°C) | 30hrs intermittent use |
| Weight | 2.5kg/5.5lbs including batteries |
| Dimensions | 113mm (H) x 206mm (D) x 250mm (W) |
| Extended self-test | Induction and Connection Modes |
| Power output levels | 4 |
