Description
Leica Rugby CLAx 700 Hz/Vt Dial-In Dual Grade Laser ±15% with Combo+ Receiver & Li-Ion
Equipped with all available functionalities, the Rugby CLAx is the “all on board” laser.
With grade dial in on the laser there is no compromise of flexibility and features for all your needs. You pay for the functionality you need to do your job without paying for the extra features that you don’t use.
CLAx 700
Fast, precise, and flexible
From installing facades to landscaping, the CLAx 700 offers digital dual grades up to 15% for both horizontal and vertical tasks. With a fast head speed and self-levelling, you get precision performance without downtime or delays.
| LEICA RUGBY | CLAX | CLH | |
| Warranty | 5Y/2Y knockdown | 5Y/2Y knockdown | |
| Grade capability1 (X/Y Axes) | 0.15 | 0.08 | |
| Self-levelling accuracy2 | ± 1.5 mm at 30 m (± 1/16″ at 100 ft) | ± 1.5 mm at 30 m (± 1/16″ at 100 ft) | |
| Self-levelling range | ± 6° | ± 6° | |
| Operating range with Combo, RE 140/160 | 1350 m diameter | 1350 m diameter | |
| Remote range (diameter) | 600 m / 1000 ft | 600 m / 1000 ft | |
| Laser class | 2 | 1 | |
| Environmental standard | IP68/MIL-STD-810G | IP68/MIL-STD-810G | |
| Operating temperature | -20 °C to +50 °C -4 °F to +122 °F |
-20 °C to +50 °C -4 °F to +122 °F |
|
| Storage temperature | -40 °C to +70 °C -40 °F to +158 °F |
-40 °C to +70 °C -40 °F to +158 °F |
|
| Rotation speed (RPS) | 0, 2, 5, 10, 15 RPS | 10 RPS | |
| Batteries | Li-Ion | Li-Ion | |
| Battery operating time3 | 50 h | 50 h | |
| Battery charging | 5 h (full charge) 1 h fast charge = 8 h operating |
5 h (full charge) 1 h fast charge = 8 h operating |
|
| Dimensions (H × W × D) | 230 mm / 9.1 in 296 mm / 11.7 in 212 mm / 8.3 in |
230 mm / 9.1 in 296 mm / 11.7 in 212 mm / 8.3 in |
|
| Weight with batteries | 3.8 Kg / 8.4 lbs | 3.8 Kg / 8.4 lbs | |
Download Brochure
